For For Bergquist 400431 Touch screen panel membrane glass 4-WIRE 12.1" ANTIGL
- group name
- Touchscreen for other brand
- Min Order
- 1 piece
- brand name
- VICPAS
- model
- Bergquist 400431
- Nearest port for product export
- Guangzhou, Shenzhen, Hongkong, TaiWan
- Delivery clauses under the trade mode
- FOB, CFR, EXW, CPT, DDU, Express Delivery
- Acceptable payment methods
- T/T, L/C, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow
- Export mode
- Export through agents
- update time
- Sat, 02 Nov 2024 13:34:20 GMT
Packging & Delivery
-
Min Order1 piece
Briefing
Detailed
CMTouch Information & Technology.Co.,Ltd. In Guangzhou, China. We are mainly design and produce touch screen glass and membrane switch keyboard which is especially used in HMI, Kiosk, Pos, Medical Machine, Touch LCD monitor and many other part which need touchscreen and membrane switch keyboard. We can also designe with your sample or request.We focus on delivering a high quality product that meets your exact specifications, and exceeds your expectations.
Data sheet:
1.All product are new and original packaging.
2.click on the precise, easy use.
3.reflecting the sensitive.
4.meet bad environment.
5.practicability.
6.no need change any shell and add any auxiliary to the HMI machine.
7.The quality is stable and reliable, took 12months warranty.
8.OEM is available.
Product specification:
NO. | Product structure | Material | Remarks |
1 | upper circuit | ITO FILM | 0.188mm |
2 | lower circuit | ITO GLASS | 2.0mm |
3 | spacer | Adhesive | 0.1mm |
4 | tail | FPC |
Environmental characteristics
NO. | Item | Specification |
1 | Operation temperature | -10℃～+60℃ |
2 | Storage temperature | -20℃～+70℃ |
Electrical characteristics
NO. | Item | Specification | Remarks |
1 | Rated Voltage | DC 5V 1mA | |
2 | Linearity | ≤3.0％ | Load 120gf |
3 | Resistance | / | FPC At connector |
/ | |||
4 | Insulation Resistance | ≥20 MΩ | DC 25V |
Mechanical characteristics
NO. | Item | Specification | Remarks |
1 | Operating force | 20-150g | R0.8 by pen |
2 | Hardness of surface | ≥4H | JISK5400 |
3 | Light Transmission | ≥80% | |
4 | FPC Bending | 1.0mm, more then 3time | 3.2 |
5 | FPC peeling strength | level180, 0.5kgf 10mins | 3.2 |
You can learn more details in below:
For For Bergquist 400431 Touch screen panel membrane glass 4-WIRE 12.1" ANTIGL
For Bergquist400384 Touch screen panel membrane glassSCRN 5-WIRE 15.0" ANTI-GLR
For Bergquist400392 Touch screen panel membrane glassSCRN 5-WIRE 19.2" ANTI-GLR
For Bergquist400425 Touch screen panel membrane glass 4-WIRE 3.9" CLEAR
For Bergquist400333 Touch screen panel membrane glassSCRN 5-WIRE 3.5" ANTI-GLR
For Bergquist400426 Touch screen panel membrane glass 4-WIRE 5.7" ANTIGLR
For Bergquist 400551 3.5 PROJ CAPACITIVE Touch screen panel membrane glass
